HS-G3015B-F30/F60
Dual-drive Pipe and Plate
Fiber Laser Cutting Machine
- This machine expertly cuts metal sheets of 0.5-16mm carbon steel, 0.5-8mm stainless steel, 0.5-6mm brass, and 0.5-4mm copper. It can also precisely cut various pipe shapes such as square, round, rectangle, D-shaped, and hexagonal. The cutting capacity for square pipes ranges from 2020 to 100100mm, round pipes from Φ20 to Φ150mm, with thicknesses of 0.5-5mm for carbon steel pipes and 0.5-5mm for stainless steel pipes.
Pipes
- The machine is adept at cutting a variety of pipes including square, round, rectangle, D-shaped, and hexagonal pipes. It can handle square pipes from 2020 to 100100mm, round pipes from Φ20 to Φ150mm, with thicknesses of 0.5-5mm for carbon steel pipes and 0.5-3mm for stainless steel pipes.
Plates
- It can efficiently cut plates made of 0.5-12mm carbon steel, 0.5-6mm stainless steel, 0.5-3mm brass, 0.5-2mm copper, as well as galvanized steel, electrolytic steel, and silicon steel. The maximum thickness varies depending on the type of material and the power of the fiber source.
High Quality Carbon Steel Welding Machine Bed
Through simulation and anlaysis of static and dynamic structural mechanical property design, the main body is welded with high-quality carbon structural steel with tensile strength up to 500MPa.
Full Automatic Double Pneumatic Chuck
One-key clamping, automatic centering, 3 times of the speed of the electric chuck; Pneumatic clamp, large and constant clamping force, no loosening and slipping of heavy tube; Specialized tube support can avoid tube sagging and deformation, improving the cutting accuracy and extending the service life of the chuck.
